S520F

Soft ice cream machine

Two hoppers,2+1 twist flavor

Double systems, one-to-one control

Separate control system, one compressor controls one system

Continuous discharging ability

Keep discharging even during the peak time

Intelligent fault detection

Intellectual detection, multiple security

Safety and energy-saving

Adopt the most advanced soft-starting technology, safer and more energy-saving

Standby function

Keep the temperature of the hopper and cylinder remain 1-4.5℃ in the evening

Mixing in the hopper

Agitator in the hopper makes the temperature of the mixture equal and the effect of pre-cooling better

• Model: S520F
• Type: Floor model
• Production capacity: 50L/H
• No. of hopper: 2
• Hopper capacity: 12.5L*2
• Cylinder capacity: 2.0L*2
• Specification: 855*636*1517mm
• Carton size: 990*770*1640mm
• N.W.: 226Kg
• G.W.: 241Kg
• Power: 3.2KW
• Beater type: SS304
• Self-check
• Hopper agitator
• Mix-low alarm

• No. of compressors: 2
• Compressor capacity: 3753BTU/h*2
• Compressor brand: EMBRACO/TECUMSEH
• Gas of compressor: R404a
• Refrigeration type: Air cool

• No. of motor: 2
• Voltage type: 220V/380V-50Hz/60Hz
• Motor capacity: 550W*2

• Air pump
• Up ventilation
• Air cool
